NPC Electric Supplies 2000 kVA Pad-Mounted Transformer for Venezuela Energy Infrastructure
2025-09-11
NPC Electric is proud to announce the successful delivery of a 2000 kVA three-phase pad-mounted transformer to Venezuela for a major electrical infrastructure project scheduled for August 24, 2025.
The supplied pad-mounted transformer includes:
-
Capacity: 2000 kVA
-
Voltage: 6.9 kV (HV) / 480/277 V (LV)
-
Frequency: 60 Hz, Vector Group: Dyn11
-
Windings: Aluminum HV/LV
-
Cooling System: Oil-cooled
As a trusted pad-mounted transformer manufacturer and supplier, NPC Electric ensures its products meet strict quality standards, offering durability, energy efficiency, and reliable performance. The oil-immersed design enhances cooling efficiency and extends the service life of the transformer under continuous heavy load conditions.
Benefits of NPC Electric Pad-Mounted Transformers
-
Compact design for urban and industrial distribution networks
-
Aluminum winding technology for cost efficiency and durability
-
Oil-cooled system for stable long-term operation
-
Easy installation and minimal maintenance requirements
This delivery reflects NPC Electric’s commitment to providing high-performance distribution transformers and supporting sustainable energy infrastructure across Venezuela and the broader Latin American region.
With expertise in power distribution solutions, NPC Electric continues to strengthen its global presence through:
-
Reliable logistics and on-time delivery
-
Tailored transformer solutions for diverse grid requirements
-
Dedicated technical support and after-sales service
By supplying advanced pad-mounted distribution transformers, NPC Electric contributes to building safe, resilient, and sustainable power systems in Latin America.
